Technical Specifications
| Frequency Range | 902 MHz to 928 MHz (US) or 865 MHz to 868 MHz (EU) |
| Protocol | (EPC C1 Gen2)ISO 18000-6C |
| Communication Port | RS232, RS485, Wiegand orTCP or IP, WIFI, GPRS Modbus RTU (selectable) |
| Polarization | Circular Linear |
| Input or Output Port | 2 channel relay output (selectable), 1 channel trigger input |
| Read Tag | Multi-tags |
| Color | White |
| Material | ABS |
| Application | Access control |
| Reading Range | 0 ft to 98.4 ft (0m to 30 m) depend on the RFID antenna |
| Power Supply | 9 V to 12V or 3A |
| Development Package | Provide DEMO software, SDK & C#, VC, Java development routines |
| Features | 6000V industrial high voltage lightning protection, extremely cold area warm treatment, anti copy |
| Protection Grade | IP65 |
| Payment Method | T or T |
| Material | ABS |
| Interface | RS232,TCP or IP |
| SDK | C# or Java |
| Size | 17.5 in x 17.5 in (445 mm X 445 mm) accept customized |
