Overview
The Inventory Master 4G external antenna cellular modem supports the maximum rate of 150 Mbps, 50 Mbps. Relying on 2 x 2 MIMO technology, it provides high-quality data communication and optimized Wi-Fi data transmission. Diversified Wi-Fi standards and encryption modes ensure the safety and stability of the product. With a variety of working modes (4G to Wi-Fi, 4G to cable), rich network protocols and reliable connections, it can be widely used in business and home. It has the function of regular restart and firewall protection. The built-in hardware watchdog can effectively prevent the system from crashing during operation. Built in dual firmware can automatically recover the system due to software upgrade failure or abnormal startup caused by software.
Features
- OEM, ODM offered
- Can customized your logo, package, firmware, change IMEI, lock bands
- Fast speed, 1200 M High Speed Dual Frequency
- Strong signal
- Multiuser
- Wi-Fi Encryption
- Firewall
- Watch Dog
- Plug and Play
- 4G to Wi-F
- 4G to Wired
- 4 Rotatable Antenna, stronger Singal
- One button to turn on, off Wi-Fi, Wi-Fi switch
- Support WPS Fast Connection
- Heat Dissipation, Stable Operation
Technical Specifications
| Network | 4 x LAN, 1 x WAN |
| SIM | 2 FF SIM |
| Button | Power Reset WPS |
| DC Adapter | Input voltage 12 V, 1.5 A |
| Routing & Wi-Fi chipset model | MT 7628 A and MT 7612 E |
| Routing & Wi-Fi processor info | IEEE 802.11 a, b, g, n, ac |
| DDR, SPI | 64 Mbytes, 16 Mbytes |
| Main antenna | External antenna |
| Receive diversity antenna | External antenna |
| Wi-Fi band | 2400 MHz to 2483.5 MHz, 5170 MHz to 5835 MHz |
| MIMO for Wi-Fi | 2.4G 5 dbi x 2 5.8G 5 dbi x 2 |
| Max. transmitter power for Wi-Fi | 802.11 a 14 dBm ±2 dBm 802.11 b 22 dBm ±2 dBm 802.11 ac 15 dBm ±2 dBm |
| LED Indicator | Supported |
| Wi-Fi standard | 802.11 a, b, g, n, ac (2 x 2 11 n features) |
| Wi-Fi security | WPA, WPA 2 |
| OS | Windows XP, Windows Vista, Windows 7, Windows 10, MAC, Linux |
| Browser | IE (8.0 and later), Firefox (3.0 and later), Safari (4.0 and later), Opera (10.0 and later), Chrome (10.0 and later) |
