Technical Specifications
| Private Mold | No |
| Ports | 8 Ethernet ports (M12 Ports) |
| Condition | New |
| Power | DC: 12 V to 52 V, PoE: 48 V to 57 V |
| Packet Forwarding Rate | 11.9 Mpps |
| MAC Table | 4 K |
| Power Port | M12 A-coded 5-pin female connector |
| Power Indicator | PWR, Link/ACT, PoE |
| Installation Method | Wall-mounted, front plug-in outlet |
| Electrical Ports | 8 x M12 X-coded, 8-pin female connector |
| Switching Capacity | 16 Gbps |
| Cache | 2 Mb |
| PoE Extension | 8 x PoE/PoE+ |
| Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x |
| Working Mode | Full-duplex, half-duplex auto-negotiation, MDI/MDI-X adaptation |
| Humidity | Working: 10 % to 9 0% RH non-condensing, Storage: 5% to 95 % RH non-condensing |
| Heat Dissipation Method | Natural cooling (finless) |
| Size (Alternative) | 6.693 in x 5.197 in x 1.622 in (17 cm x 13.2 cm x 4.12 cm) |
| Temperature | Working: -40°F to 167°F (-40°C to 75°C), Storage: -40°F to 185°F ( -40°C to 85°C) |
