Overview
The BLE 5.0 Magnetic Door Sensor Beacon is a compact, low-power solution for real-time monitoring of doors, windows, or drawers. Easy to install with adhesive, it uses a replaceable CR2032 battery for up to 16 months of life. With iBeacon and Eddystone support, a 100m range, and compatibility with iOS/Android, it’s ideal for security, asset monitoring, and inventory systems, ensuring reliable performance in various environments.
Features
- BLE 4.0 and BLE 5.0 compatibility
- Magnetic sensor for door or window detection
- 0.062 mi (100 m) transmission range
- Compact and lightweight design
- Double-sided adhesive for easy installation
- Replaceable CR2032 battery with 16-month lifespan
- iBeacon and Eddystone protocol support
- Compatible with iOS and Android devices
Applications
- Home Security Systems
- Office Door Monitoring
- Smart Home Automation
- Entry and Exit Tracking
Technical Specifications
| BLE Version | BLE 4.0 or BLE 5.0 |
| Sensor Type | Magnetic sensor |
| Transmission Range | 0.0621 mi (100 m) in open areas |
| Protocol Support | iBeacon, Eddystone, KBeacon |
| Battery Life | Up to 16 months (at 1-second interval and 0 dBm power) |
| Data Storage | 40000 records |
| Installation Method | Double-sided adhesive |
| Color | White (custom colors available) |
| Operating Temperature | -4 °F to 140 °F (-20 °C to +60 °C) |
| Optional Temperature | -22 °F to 158 °F (-30 °C to +70 °C) |
| Dimensions (Sensor) | 2.05 in x 1.02 in x 0.57 in (52 mm x 26 mm x 14.5 mm) |
| Dimensions (Magnet) | 0.98 in x 0.47 in x 0.55 in (25 mm x 12 mm x 14 mm) |
| Weight | 0.63 oz (18 g, with battery) |
