Features
- Accurate Distance Measurement
- Built-In Micro Printer
- High Sampling Frequency
- Advanced Storage Capabilities
Technical Specifications
| Screen | Industrial-grade 5-inch LCD display |
| Control | Single-chip microcomputer, keyboard operation |
| Functions | Distance, speed, resistance measurement |
| Sampling Method | Flashover sampling, low-impulse method |
| Sampling Frequency | 30 MHz, 60 MHz, 120 MHz |
| Test Distance | Up to 102.5 mi (165 km) |
| Pulse Width | 0.2 µs to 9.9 µs |
| Deviation | No more than ± 0.25% |
| Pre-locating Accuracy | Absolute ± 32.8 ft (10 m); Relative ±1% |
| Power Supply | Built-in 2.6 V / 10.4 Ah DC battery; External AC 220 V 50 Hz |
| Battery Type | Nickel hydrogen with charger |
| Printer | Built-in micro printer for waveforms and reports |
| Waveform Functions | Left/right displacement, compression for clarity |
| Computer Communication | Compatible for data transfer |
| Data Storage | Stores up to 10 test waveforms |
| Operating Temperature | -13 °F to 149 °F (-25 °C to 65 °C) |
| Monitor Viewing Angle | >160° |
| Test Mode | Low pressure plus, multiple pulse, voltage sampling |
| Dimensions | 16.9 in × 14.2 in × 9.1 in (43 cm × 36 cm × 23 cm) |
| Weight | 17.6 lbs (8 kg) |
