Features
- Fast test reaction time
- Wire sequence detection
- Multi-pin continuity testing
- Customizable test results
- Clear test feedback
Technical Specifications
| Vision Test Range | Width: 0.04 in to 3.94 in (0.1 cm to 10 cm) |
| Voltage | 200 Vac to 240 Vac 50 Hz / 60 Hz |
| Colour Test | Wire sequence misordering, misplacement, wrong pin |
| Continuity Test | 64 PIN continuity, open circuit, instantaneous open test |
| Test Result | Voice broadcast, NG lock |
| Applicable Products | Wire harness, single end, industrial computer motherboard |
| Test Reaction Rate | 0.03 s |
| Extra Function Customize | Printing and Dotting |
| Working Environment | Temperature: 23 °F to 104 °F (-5 °C to 40 °C) Relative Humidity: < 80% |
| Size | 22.05 in x 17.32 in x 17.72 in (56 cm x 44 cm x 45 cm) |
| Weight | 44.09 lbs (20 kg) |
