| Dynamic Range | 45/42/42/42 dB |
| Power Meter | Built-in |
| Laser Source | Built-in |
| VFL (Visual Fault Locator) | Built-in |
| Display | 7 in TFT color touch |
| Weight | 8.82 lb. (4 kg) (maximum dynamic range) |
| Ranging Accuracy | ± (0.75 + sample interval + 0.0025% × range) (m), excluding refractivity placement error |
| Ranging Resolution | 0.164 ft (0.05m), 0.328 ft (0.1m), 0.656 ft (0.2m), 1.640 ft (0.5m), 3.281 ft (1m), 6.562 ft (2m), 13.123 ft (4m), 26.247 ft (8m), 52.493 ft (16m), 104.987 ft (32 m) |
| Test Range (Mono-mode) | 0.249 mi (0.4 km), 0.497 mi (0.8 km), 0.994 mi (1.6 km), 1.988 mi (3.2 km), 3.977 mi (6.4 km), 9.942 mi (16 km), 19.884 mi (32 km), 39.768 mi (64 km), 79.536 mi (128 km), 159.072 mi (256 km), 318.144 mi (512 km) |
| Test Range (850nm multi-mode) | 0.249 mi (0.4 km), 0.497 mi (0.8 km), 0.994 mi (1.6 km), 1.988 mi (3.2 km), 3.977 mi (6.4 km), 9.942 mi (16 km), 19.884 mil (32km) |
| Testing PW (Pulse Width) | 3, 5, 10, 30, 80, 160, 320, 640, 1280, 5120, 10240, 20480 ns |
| Testing PW (850nm multi-mode) | 3, 5, 10, 30, 80, 160, 320, 640, 1280 ns |
| Maximum Number of Sampling Points | 256k |
| Linearity | 0.03 dB/dB |
| Loss Resolution | 0.001 dB |
| Refractivity Setting Range | 1.00000 to 1.99999 (step: 0.00001) |
| Range Unit | km, m, thousand feet, feet |
| Display Resolution | 800 × 480, 7 in TFT color LCD |
| Optical Output Interface | FC/UPC (standard), LC/UPC, SC/UPC, ST/UPC optional |
| Interface Language | Simplified Chinese, English, Russian, Korean (other languages available upon request) |
| External Interfaces | USB, Micro-USB, 10M/100M Ethernet, earphone, Micro SD |
| Power Supply | AC/DC Adapter: AC 100V to 240V, 50/60Hz, 1.5A; DC: 17V ±3V (2A) |
| Internal Li Battery | 11.1V, 6800mAh, 8 hours operating time |
| Power Consumption | 10W |
| Dimensions | 9.92 in × 7.09 in × 2.17 in (25.2 cm × 18 cm × 5.5 cm) |
| Weight (Unit) | About3.97 lb. (1.8 kg) |
| Operating Temperature | 14 °F to 122 °F (-10 ℃ to +50℃ ) (battery charging: 41 °F to 104 °F (5 ℃ to 40 ℃) |
| Storage Temperature | -40 °F to 158 °F (-40 ℃ to +70 ℃) (battery: -4 °F to 140 °F (-20 ℃ to 60 ℃) |
| Relative Humidity (RH) | 5 % to 95 %, no condensation |
