Features
- Compact Lightweight Design
- Long Battery Duration
- One-Key Auto Testing
- Durable Shock-Proof Build
Technical Specifications
| Wavelength | 1310 nm / 1550 nm / 1625 ± 20 nm |
| Fiber Type | G.652 Single-Mode Fiber |
| Dynamic Range | 28 dB / 26 dB |
| Event Blind Zone | 9.8 ft (3 m) |
| Attenuation Blind Zone | 26.2 ft (8 m) |
| Test Range | 3.1 mi to 49.7 mi (5 km to 80 km) |
| Pulse Width | 5 ns to 10 μs |
| Ranging Accuracy | ± (3.28 ft + Sampling Interval + 0.005% × Test Distance) |
| Linearity | ±0.2 dB / dB |
| Sampling Points | 16k to 128k |
| Sampling Resolution | 1.97 in to 26.2 ft (0.05 m to 8 m) |
| Reflection Accuracy | ±3 dB |
| Data Storage | Internal: ≥600 results; External: TF Card |
| Laser Safety Level | Class II |
| File Format | SOR Standard File Format |
| Connector | FC/UPC (Interchangeable SC/ST) |
| Display | 4.3-in Color LCD |
| Data Interface | Micro USB |
| External Storage | TF Card |
| Power Supply | 3.7V 4000mAh Polymer Li-Battery, 5VDC 2A Adapter |
| Battery Life | Standby: >20 hours, Measurement: >12 hours |
| Operating Temperature | 14 °F to 122 °F (-10°C to 50 °C) |
| Dimension | 7.09 in × 4.33 in × 1.73 in (18 cm × 11 cm × 4.4 cm) |
| Weight | ≤0.88 lb. (400 g) |
