Features
- OTDR full function OTDR that also allows active fiber testing
- LTDR can test copper wires & networks cables
- Short circuit point and impedance mis-match point
- OPM to check optical signal level
- PON power meter- can check OLT or ONU
- VFL check fiber faults visually
- Network test no need of laptop
- Link test can test PING to the router or gateway
- Line test- measure the loop resistance
- Unbalance resistance to judge the condition
- Test the line sequence
- Setting Help
Technical Specifications
| Wavelength Range | 800 nm to 1600 nm |
| Power Measurement | -70 dBm to +6 dBm (-50 dBm to +25 Broadcasting) |
| Uncertainty | Uncertainty |
| Display Resolution | 0.1 dBm |
| Connector | SC |
| Wavelength Range | 1277 nm to 1310 nm |
| Measurement Range | -30 dbm to + 6 dbm |
| Insert Loss | Less than 1 dB |
| Uncertainty Value | ±1 dBm |
| Operation Wavelength | 650 nm |
| Output Power | 5 mW |
| Modulation | 0 Hz,1 Hz, 2 Hz |
| Download Speed | 1000 M |
| Ping Test | 6 groups or setting |
| 4 Groups Loop Resistance | 1 Ω to 8000 Ω |
| 4 Groups Unbalanced Resistance | 1 Ω to 1000 Ω |
| Uncertainty | 5% |
| Audio Hunt | 800 Hz to 1600 Hz to 10 vpp |
| Ultra-audio Hunt | 400 kHz Modulation 800 Hz to 1600 Hz to 10 vpp |
| Measurement Resolution | 1.96 ft (0.6 m) |
| Event Dead Zone | 49.21 ft (15 m) |
| Attenuation Dead Zone | 65.61 ft (20 m) |
| Test Pulse Width | (10 ns, 30 ns, 100 ns, 300 ns, 1 us, 3 us |
| Scattering Depth | 12 dB |
| Measurement Length (Event) | 31.06 mi (50 km) |
| Measurement Length (Attenuation) | 18.64 mi (30 km) |
| Measuring Length | 16.40 ft to 1.24 mi (5 m to 2000 m) |
| Test The Pulse Amplitude | 10 v |
| Test Pulse With | 10 ns, 30 ns, 100 ns, 300 ns, 1 us, 3 us |
| Power Supply | Lithium or 4000 MAH |
| Power Adaptor | Micro-USB 5 V or 1000 mA |
| Single-phase Maximum current | ≤200 mA |
| Standby Power | ≤2 uA |
| Battery Operating Time | ≥10 H |
| Working Temperature | 14° F to 122° F (-10° C to +50° C) |
| Storage Temperature | -13° F to 158° F (-25° C to +70° C) |
