Features
- Customizable wavelength combinations
- Online light alarm
- Fiber link map function
- Remote PC control
Technical Specifications
| Accessories | Power adapter, USB cable, Quick guide, Carrying bag |
| Built-in Fiber Link Measurement | Yes |
| Built-in Laser Source | NO |
| Connector Type | SC/ST |
| Dead Zone | 2.62 ft to 13.12 ft (0.8 m to 4 m) |
| Display | 7 in TFT-LCD (touch screen optional) |
| Distance Accuracy | ± (1 m + test distance × 3 × 10⁻⁵ + sampling resolution) |
| Distance Range | SM: 328.1 ft to 787402 ft (100 m to 240 km); MM: 1640.4 ft to 262467 ft (500 m to 80 km) |
| Distance Resolution | 0.01 m (0.03ft) |
| Dynamic Range | 35 to 33dB |
| Humidity | ≤95% (no-condensation) |
| IOR | 1.2000 to 1.7000 |
| Interface | 1 x RJ-45, 3 x USB (Type A x2, Type B x1) |
| Linearity | ≤0.05 dB/dB |
| Loss Resolution | 0.001 dB |
| Loss Threshold | 0.01 dB |
| Memory Capacity | 80,000 Curves |
| OPM | 850 to 1650nm; Test range: -60 dBm to +5dBm |
| Optical Line Map (FLM/iOLM) | Yes |
| Optional | SC/LC adapter, Fiber microscope, Launch cable box |
| Pulse Width | SM: 3 to 20ns; MM: 3 to 1us |
| Sampling Points | Max 128,000 |
| Sampling Resolution | Min 0.16ft (0.05m) |
| VFL | 10 mW, CW to 2Hz |
| Wavelength | 1310 nm to 1550 nm |
| Operating Temperature | -4 °F to 158 °F (-20 °C to 70°C) |
| Dimension | 9.96 in x 6.61 in x 2.9 in (25.3 cm x 16.8 cm x 7.36 cm) |
| Weight | 52.91 oz (1.5kg) |
