Features
- Dual-wavelength optimization
- High-speed network testing
- Intelligent one-key operation
- Extended battery life
Technical Specifications
| Center Wavelength | 1310/1550 nm |
| Dynamic Range | 24/22 dB |
| Pulse Widths | 10 ns, 20 ns, 50 ns, 100 ns, 300 ns, 1.0 µs, 2.5 µs, 10 µs, 20 µs |
| Event Dead Zone | (2 m) 6.56 ft |
| Attenuation Dead Zone | (10 m) 32.8 ft |
| Distance Range | 0.5 km to 80 km (0.31mil to 49.7 mil) |
| Distance Measurement Accuracy | ±(1 m + Sampling Space + Measurement Distance × 0.005%) |
| Linearity | ±0.05 dB/dB |
| Visual Fault Locator (VFL) | Center Wavelength: 650 nm ±20 nm; Output Power: <1 dBm; Fiber Type: SMF |
| Memory Capacity | 1000 Traces |
| Display | 3.5-inch LCD |
| Interface | FC/UPC |
| Optical Connector | FC/SC/ST (Universal Connector) |
| Battery | NiMH Smart Charge Battery; Continuous Working Time: >10 Hours |
| Dimensions | 9.06 in x 4.72 in x 2.36 in (23 cm x 12 cm x 6 cm) |
| Weight | 1.98 lbs (0.9 kg) |
