Overview
The Inventory Master handheld UHF RFID reader is an android rugged mobile computer. It features a quad-core processor, 800 mAh battery and superb UHF RFID capability. It can be equipped with R2000 linearly or circularly polarized antenna. That it can read tags in bulk from long distance enables it to be deployed in asset management, retail, warehousing, fleet management etc.
Technical Specifications
| Frequency | 902 MHz to 928 MHz |
| Protocol | ISO18000-6C/EPC C1 GEN2 |
| Antenna Parameters | Linearly polarized antenna |
| Display | 5.2 in (13.2 cm) |
| Touch Panel | Multi-touch panel |
| Protection Level | IP65, meeting IEC sealing standard |
| Battery Capacity | Rechargeable lithium polymer battery 8000 mAh |
| MOQ | 1 |
| Power Supply | 3.7 V 4000 mAh Li-ion Battery |
| Power | 1 W |
| Reading Or Write Rate | 82.02 ft (25 m) (circular polarization) 32.8 ft (10 m) (circular polarization) 68.8 ft (21 m) (linear polarization) 22.9 ft (7 m) (linear polarization) |
| Group Read Rate | 200 tags per s |
| Barcode Scanning | 1D Linear Scanner |
| Version | English |
| Customized Service | Logo printing, Series No. printing, Encoding, Size |
| Interfaces | USB 2.0 Type-C |
| Working Temperature | -4 °F to 122 °F (-20 ℃ to +50 ℃) |
| Storage Temperature | 40 °F to 158 °F (-40 ℃ to 70 ℃) |
| Humidity | 5 % RH to 95 % Rh non considering |
| Dimensions | 6.4 in X 3.1 in X 0.9 in (164.2 mm X 80.0 mm X 24.3 mm) |
| Machine Size | 6.4 in X 3.1 in X 0.9 in (164.2 mm X 80 mm X 24.3 mm) |
| Machine Weight | 23 oz (654 g) |
