Features
- X2 View support HTML5
- Web browser show web configuration pages by any devices, no plugins required
- Support more than 248 protocol, Upload data to cloud server by MQTT and remote monitor, Open data interface to third party system integration
- Modular Configurability
- Supports WIFI
Technical Specifications
| Chipset | WEB Configuration Gateway |
| Application | M2M IoT, M2M and IoT Application |
| Supplier Type | IOT Application |
| Interface | 2Ethernet ports,2 RS485 Serial Ports |
| Chipset | ARM |
| Type | Ethernet Module |
| Power Consumption | 6W |
| Systems | LINUX |
| Installation | Guide rail type |
| Flash | 420.26 feet (128 M) |
| Power Supply | 24V AC or DC |
| AI (Read-Only) | 256(0 to 255) |
| AO (Read and Write) | 256(0 to 255) |
| AV (Read and Write) | 256(0 to 255) |
| BI (Read-Only) | 256(0 to 255) |
| BO (Read and Write) | 256(0 to 255) |
| BV (Read and Write) | 256(0 to 255) |
| MI (Read-Only) | 256(0 to 255) |
| MO (Read and Write) | 256(0 to 255) |
| MV (Read and Write) | 256(0 to 255) |
| 0X(Coil Status) Read and Write | 256(1 to 256) |
| 1X(Input Status) Read-Only | 256(1 to 256) |
| 4X(Holding Register) Read and Write | 256(1 to 512) |
| 3X(Input Register) Read-Only | 256(1 to 512) |
| Memory | 1,677.11 feet (512 M) |
| Operating System | Linux |
| Flash | 8GB |
| Ports | 2 Network Port, 4 RS485 Ports, 1 232 Serial Port |
| Power Consumption | ≤8W |
| Power Supply | AC or DC 12 V to 24V (Recommended: DC) |
| Humidity | 320% to 90% No Condensation (at work) 15% to 95% No Condensation (Storage and Transportation) |
| Temperature | -4°F to 158°F(-20 to 70℃) (at work) -40°F to 185°F (-40 to 85℃) (Storage and Transportation) |
| Hole | Size: 10.12 in x 6.93 in (25.7 cm x 17.6 cm) Size: 5.79 in x 3.70 in x 1.38 in (4.7 cm x 9.4 cm x 3.5 cm) |
| Weight | 0.66 lbs (0.3 kg) |
