Features
- Flexible connection
- Practical tools
- Test management or report
- To PC as the guidance
- Power Management
Technical Specifications
| Wavelength | 850/1300/1310/1490/1550/1625/1650 nm |
| Dynamic Range | Up to 39 dB |
| Screen | Touch screen, Colour, 800×480 TFT, 1,78 cm (7 inch) |
| Connector | Two USB 2.0 ports, RJ-45 LAN 10/100/1000 Mb/s, Optical fiber probe end connection checks (video), Built-in Bluetooth and WIFI (optional) |
| Storage | 8GB internal memory (flash memory), 16GB internal memory (flash memory) (optional) |
| Battery | Replaceable lithium-ion battery, 8 hours operating time, Telcordia (Bellcore), Optional extended time batteries |
| Power Supply | AC/DC adapter, input 100 VAC to 240 VAC, 50 Hz to 60 Hz, 2 A maximum, 24 VDC output, 90 W |
| Main Engine | Intel Atom processor, Windows Embedded operating system (standard version) |
| Vibration | < 0.053 oz (1.5 g) at 10 Hz to 500 Hz (on three main axes) |
| Mechanical Shock | < 29.92 in (76 cm) on six sides and eight main edges (according to GR-196-CORE) |
| Weight | 2.5 kg (5.4 lb) |
| Size (H x W x D) | 12 11/16 in x 7 3/4 in x 4 5/16 in (3.22 cm x 1.97 cm x 1.09 cm) |
| Relative Humidity | 0 % to 95 % non-condensing |
| Operating Temperature | 23 °F to 122 °F (-5 °C to 50 °C) |
| Storage Temperature | -40 °F to 158 °F (-40 °C to 70 °C) |
