| Product Type | Fiber Test and CCTV Tester |
| Warranty Time | 1 Year |
| Network | Wired LAN, ONVIF, POE, Wi-Fi |
| Display | 8-Inch Retina Screen, 2048×1536 Resolution |
| Wavelength | 1310/1550nm |
| Dynamic Range | 28/26dB |
| Testing Distance | 80.78 mi (130 KM) |
| Camera Type | H.265 & H.264 IP Camera Test, HD Coaxial Camera, 8MP AHD CVI TVI Camera Test |
| Visual Fault Locator | Support |
| Power Output | DC24 2A, DC12V 3A, and 48V POE |
| Optical Power Meter | Support |
| Cable Tracer and Cable Tester | Support |
| Wavelength (nm) | 1310/1550 |
| Dynamic Range (dB) | 32/30 |
| Pulse Width (ns) | 5, 10, 20, 40, 80, 160, 320, 640, 1280, 2560, 5120, 10240, 20480 |
| Testing Distance | 93.21 mi (≤150 KM) |
| Event Blind Zone (m) | 7.87 Feet (≤2.4 m) |
| Attenuation Blind Zone (m) | 45.93 Feet (≤14 m) |
| Linearity (dB/dB) | ±0.05 dB/dB |
| Loss Threshold (dB) | 0.05 |
| Loss Resolution Ratio (dB) | 0.01 |
| Sampling Resolution Ratio (m) | 0.125 to 8 |
| Sampling Point | 32K |
| Distance Uncertainty (m) | ± (1 m + 5×10-5× Distance + Sampling Interval) |
| Distance Scope (km) | 0.62 mi (1 km), 3.11 mi (5 km), 6.21 mi (10 km), 18.64 mi (30 km), 37.28 mi (60 km), 62.14 mi (100 km), 111.85 mi (180 km) |
| Typical Real-Time Refreshing Duration | 1s |
| Measurement Duration | 5 sec, 10 sec, 15 sec, 30 sec, 1 min, 2 min, 3 min are selectable |
