Technical Specifications
| Frequency | 1Sm 902 MHz to 928 MHz |
| Reading or Writing Capability | Capability of Reading or Writing agreement of ISO18000-6B, EPC Passive tags and software programmable. Able to decode ISO-18000B, EPC. Reading Range (Max): 16.40 ft (5 m) Reading Range (Reliable): 8.20 ft (2.5 m) |
| Operation Mode | Fixed Frequency or FHSS or Software Programmable |
| RF Power Output Adjustable | Power Output Adjustable Range: 0.1 W to 1 W |
| Built- In Antenna Type | Built-In Circularly polarized antenna. |
| Communication Ports | RS-232 or RS-485 or Weigand 26 bits or 32 bits |
| Communication Rates | Up to 57,600 bps and software programmable |
| Programmable Application Platform | 1) Allows Programmable Interface with host applications 2) Currently Supports Visual Basic or VC applications |
| Power Consumed | +5 V DC, Average power of less than 2 W |
| Dimension | 8.6 in x 8.6 in x 19.6 in (220 mm x 220 mm x 500 mm) |
| Weight | 3.3 lb (1.5 kg) |
