Overview
The Inventory Master Antenna Long-distance Integrated Reader RS232 UHF RFID is a high-Performance UHF integrated reader for long range operation. Compact Reader with integrated 12 dBi linear polarized UHF Far Field antenna. Based on proprietary efficient digital signal processing algorithm, the reader is capable of up to 49.2 ft (15 m) Read Range and 19.6 ft (6 m) Write Range.
Technical Specifications
| Frequency | EUR 865 MHz to 868 MHz or USA 902 MHz to 928 MHz or International 920 MHz to 925 MHz Others (Customized Tag） |
| Protocol | ISO18000-6C (EPC GEN2) |
| Read Range | > 49.2 ft (15 m) |
| Group Of Reading Performance | > 20 PCS |
| Frequency Hopping Mode | Fixed Frequency Band and FHSS Software Programmable |
| Operating Mode | Master-Slave Mode (Online Mode) Time Scheduled Modes Trigger Mode |
| Output Power | 0 dBm to 30 dBm (Adjustable) |
| Antenna | 12 dBi linearly polarize antenna (Integrated) |
| Communication Port | RS232, RS485, Wiegand26, Wiegand34, RJ45, WIFI, GPRS |
| System Parameter | ARM7 + UHF model |
| Power | +12 V |
| Prompt | Beep or LED light flash |
| Power Consumption | < 3 W |
| Software Pack | API Software Development Kits complete with VB, C# Sample Program |
| Humidity | 20 % RH to 95 % RH (no condensation) |
| Operating Temperature | -4 °F to 158 °F (-20 ℃ to + 70 ℃) |
| Storage Temperature | -40 °F to 257 °F (-40 ℃ to + 125 ℃) |
| Dimensions | 3.7 in x 3.7 in x 1.5 in (445 mm × 445 mm × 70 mm) |
| Net Weight | 5.5 lb (2.5 kg) |
