Overview
The Inventory Master Medical Use RFID UHF Metal Passive Ceramic Tag is designed on PPA or ceramic base material, solving the problem that tag can’t work well on the metal surface and work continuously in the high temperature environment (Withstanding 392 °F (200 °C) for one hour).It mainly is designed for metallic mold tracking, metallic high-temp containers, etc.
Technical Specifications
| Material | PPA or Ceramic |
| Protocol | ISO or IEC 18000-6 TypeC (EPC Gen2) |
| Frequency | 860 MHz to 960 MHz |
| Chip | UHF Alien Higgs-3 |
| Personalized | Chip Encoding |
| Mounting | Adhesive |
| IP Rating | IP68 |
| Data Storage | > 10 years |
| Re-Write | 100,000 times |
| Installation | 3M VHB Adhesive |
| Customization | Printing LOGO, Encoding, Designing, etc |
| Name | UHF High-temp On-metal Tag |
| Color | Black |
| Storage Temp | -40 ºF to 392 ºF (-40 ºC to +200 ºC) |
| Working Temp | -40 ºF to 392 ºF (-40 ºC to +200 ºC) |
| Humidity | 98 % non-condensing |
| Dimensions | 0.96 in x 0.76 in x 0.16 in (24.5 mm x 19.4 mm x 4.0 mm) |
| Weight | 0.17 oz (5.1 g) |
