| Master Control | Qualcomm 9531 master control chip, 128MB memory, 16M Flash |
| Power Supply | DC12V |
| LoRa Frequency | CN470-510 / EU863-870 / US902-928 / AS923 / AU915-928 / KR920-923 (Optional) |
| LoRa Communication Rate | 292bps to 5.4kbps, support spread factor SF7-SF12 |
| LoRa Tx Power | 17 dBm |
| Maximum Power | 20 dBm (at the antenna mouth) |
| LoRa Rx Sensitivity | -141 dBm at SF12 |
| LoRa Antenna Gain | 2 dBi |
| LoRa Antenna Type | Omni-direction |
| Channel | 8 uplinks, 1 downlink |
| LoRa Working Mode | Half-duplex |
| Base Station | Network |
| LTE Model | Various frequency bands |
| WiFi | 2.4GHz, AP mode, Maximum power: 18 dBm |
| Debug Interface | WiFi; LAN; serial port |
| Humidity | 5 % to 95 % |
| Power Consumption | 7W |
| Core | Linux-4.14.88 |
| LoRa Protocol | LoRaWAN V1.1 GWMP protocol, Class A / C |
| Packet Forwarding | Supports UDP (GWMP) / MQTT (GWMP) / built-in NS / WSS (based on Basic Station’s CUPS and LNS protocols) |
| Built-in NS | Up to 100 terminal connections, supporting MQTT / HTTP push decryption and data parsing |
| Modbus TCP | Up to 5 client access, supports function code 03, reads temperature, humidity, voltage, and other data |
| User Interface | WEB interface |
| Language and Interface | Chinese/English with logo or neutral interface |
| 3G/4G Networking | Supports Qualcomm universal dial-up QMI |
| IPv6 | 4G supports IPv6, LAN, and Wi-Fi provide IPv6 relay function |
| Local Time Synchronization | Supports NTP client, different time zones can be set |
| WAN Port Protocols | Static IP, DHCP client, and PPPoE. |
| Firmware Upgrade and Flashing | Supports uploading firmware fresh in WEB and OTA remote upgrade |
| Wi-Fi Connectivity | 2.4GHz, 802.11b / g / n, WPA2 PSK encryption, support STA+AP mode |
| Firewall | IP tables v1.8.2, support customized rule, SYN-flood protection |
| Network Load Balancing | Optional switching between WAN and 4G, prioritizing WAN traffic with 4G as a backup |
| Gateway ID Generation | Gateway ID generated based on WiFi MAC address |
| Local Log Management | Support logs stored in TF card, clears when full |
| Fault Self-Diagnosis | Supports system self-diagnosis, self-healing, and report results |
| Remote Management | Supports remote firmware upgrades, restarts, and maintenance |
| LoRaWAN Protocol | Supports standard LoRaWAN protocols V1.0.X (V1.0.2, 1.0.3, 1.0.4), V1.1 |
| Device Types | Supports device types Class A and Class C |
| Uplinks and Downlinks | 8 uplink channels, 1 downlink channel |
| Packet Forwarding | Supports UDP packet forwarding protocol, Basics Station CUPS, and LNS protocol |
| Server Switching | Can switch between embedded NS or external NS server as needed |
| Data Transmission | Embedded NS MQTT protocol supports data transmission even when disconnected |
| Wi-Fi Connection | Supports WiFi connection to the gateway for monitoring and configuration |
| Firewall Protection | Supports firewall protection, SYN-flood defense, and DNS rebinding protection |
| Remote Management | Supports remote OTA upgrade, self-diagnosis, and repair |
| Log Storage | Support for TF card log storage |
| RJ45 Ports | Two external RJ45 ports, one for WAN and one for LAN |
| IPv6 Support | Supports IPv6, provides public network IP addresses for LAN and Wi-Fi |
| Intelligent Switching | Supports automatic switching between WAN and 4G, prioritizing WAN |
| LTE Coverage | Supports LTE with three module options for China, Europe, and the US, ensuring full network coverage in China |
| Temperature | 14 °F to 122 °F (-10 °C to 50 °C) |
| Dimension | 7.09 in x 4.53 in x 1.18 in (18 cm x 11.5 cm x 3 cm) |
