Technical Specifications
| Source | DC24V, working range (DC9-28V), anti-surge, overcurrent, and reverse connection protection |
| Work Environment | -31 °F to 167 °F (-35 ℃ to 75℃) 10% to 90% RH (non-condensing) |
| Average Power | ≤5W |
| Networking Methods | 2G/4G(CAT.1)/Network cable |
| Communication Port | 1 x WAN or 1 x LAN 1 x 485 or 1 x 232 |
| Collection Interval | ≥500ms |
| Number Of Variables | 500 |
| Variable Expansion | Supported (up to 5000) |
| Cloud Storage Space | 100000 sets |
| Number Of Connected Devices | 16 units |
| PLC Remote Download | All serial/network devices (PLC, touch screen, others) |
| Anti Disassembly Protection | Have |
| Script Functionality | JS scripts, low code development |
| Report Statistics | Have |
| Data Storage Method | Storage methods for “cycle”, “condition”, “change”, and “expression” |
| Breakpoint Continuation | Have |
| Supporting Device Protocols | Modbus, Siemens, Mitsubishi, Omron, Delta, Xinjie, AB, Keinz, Huichuan, Yaskawa, Panasonic, Megumit, Hollyssey, Beifu, DLT645, BACnet and other protocols (most serial/network PLC) |
| 2G Frequency Band | GSM: 900/1800 MHz |
| 4G-CAT.1 Frequency Band | LTE-FDD: B1/B3/B5/B8 LTE-TDD: B34/B38/B39/B40/B41 |
| 4G-CAT.4 Frequency Band | LTE-FDD: B1/ B2/ B3/ B4/ B5/ B7/ B8/B12/B13/ B18/ B19/ B20/ B25/ B26/ B28 LTE-TDD: B38/ B39/ B40/ B41 WCDMA: B1/ B2/ B4/ B5/ B6/ B8/ B19 GSM/EDGE: 850/900/1800/1900 |
| 5G Frequency Band | 5G NR NSA: n41/n78/n79 5G NR SA: n1/n28/n41/n77/n78/n79 |
| WIFI Standard | 802.11 b/g/n 2.412GHz~2.484GHz |
| Size | 4.49 in x 3.35 in x 1.38 in (11.4 cm x 8.5 cm x 3.5 cm) |
