Features
- Light weight and small volume, High concealment
- Fast read & write, High data security and stability,
- Convenient Long read & write distance.
Technical Specifications
| Frequency Range | 902 MHz to 928 MHz |
| Polarization Type | Vertical |
| Gain | 2.5 dBi |
| 3dB Beam-Width H-Plan | 80° |
| 3dB Beam-Width E-Plan | 65° |
| VSWR | ≤1.5 |
| Front To Back Ratio | ≥20 dB |
| Input Impedance | 50 Ω |
| Max Input Power | 20 W |
| Lightning Protection | DC Grounded |
| Connector Type | SMA Female |
| Radome Material | EVA |
| Radome Colour | Black |
| Operating Temperature Range | -13 ºF to +149 ºF (-25 ºC to +65 ºC) |
| Dimensions | 3.94 in x 2.56 in x 0.12 in (100 mm x 65 x mm x 3 mm) |
