Features
- Unidirectional 3 G-SDI video with embedded audio over one fiber
- Range from 19.4 Mb/s to 2.97 Gb/s
- SMPTE 292 M (1.485 Gb/s) clock recovery
- Support all SMPTE 295 M standard, 143 Mb/s to 360 Mb/s
- Output wavelength 1310 nm,1550 nm and 16 types of CWDM
- 09 mi (150 m) automatic cable equalization, all the 1.485 Gb
- Optional network management system
- LED status indicators monitor the critical parameters
- Optional network system
Technical Specifications
| Serial TV BNC Input or Output | |
| Input Channel | 16 |
| Output Channel | 16 |
| TV Signal Standard | SMPTE 292M, 259M, 297M, 305M, 310M, M2S, DVB-ASI, DVB-SSI and other Telecom or Datacom rate (19.4 Mb/s to 1.485 Gb/s) |
| Reflection Loss | >15 dB |
| Equilibrium | 0 mi to 0.09 mi (0 m to 150 m) 1.485 Gb/s |
| Connector | 75 Ω BNC |
| Signal Level | 800 mV nominal |
| Rise or Fall Time | 200 Ps nominal |
| Overshoot | <10% amplitude |
| Reflection Loss | >15 dB |
| Jitter | <0.2 UI |
| Connector | 75 Ω BNC |
| Audio | |
| Channel | 1 (unidirectional or bi-directional) |
| Connector | Terminal Block with Screw Clamps |
| Data | |
| Channel | 1 |
| Data Format | RS232, RS-485, RS422 (full or half duplex) and support NRZ, RZI and Manchester |
| Optic | |
| Channel | 1 |
| Type | Single-mode or fiber (multimode optional) |
| Wavelength | 1310 nm or 1550 nm |
| Reflection Loss | >15 dB |
| Connector | FC or PC (ST or PC optional) |
| Power And Environmental Indicator | |
| EMI Or RFI | FCC Part 15 Class A, EU EMC standard |
| Average Time Trouble-free | >100000 hrs |
| Operating Temperature | -40 ℉ to 122 ℉ (-40 ℃ to 50 ℃) |
| Dimension | 8.97 in x 7.08 in x 1.18 in (228 mm x 180 mm x 30 mm) |
| Weight | 4.40 lb (2 kg) |
