Features
- Support 802.3x full duplex flow control
- Support network storm suppression
- Support IPv6, static routing
- Support DHCP Server, DHCP replay, Qos
- Support Web, SNMP management mode
- Support port mirroring, interface status monitoring, log management
- Support 1588 clock protocol
Technical Specifications
| PoE power | Each port 15 W / 25 W / 30 W |
| Uplink Ports | 2 port SFP slot 1 G |
| Input Voltage | 12 V DC to 57 V DC |
| Device Performance | Surge 6 KV, ESD 15 KV |
| PoE Protocol | IEEE802.3af / IEEE802.3at |
| Throughput | 14.88 Mpps |
| Packet Buffer | 2 M |
| MAC Address | 4K |
| Jumbo Frame | 4096 bytes |
| Fiber Media | Multi-mode: 1.24 ml (2 km)Single mode: 12.43 mi /24.85 mi /37.28 mi / 49.70 mi (20 km / 40 km / 60 km / 80 km) |
| Switching Capacity | 20 Gbps |
| Transfer Mode | Store and forward |
| MTBF | 100,000 hours |
| Protection | Lightening protection, IP40 protection |
| Power Supply | Input Voltage: 12 V DC to 57 V DC / Terminal block |
| Shell | IP40 protect grade, metal shell |
| Installation | DIN-Rail or Wall mounts |
| Network Protocols | IEEE802.3 IEEE802.3i IEEE802.3u IEEE802.3ab IEEE802.3z |
| PoE Specification | PoE ports: 1 to 8 ports support PoE Each PoE Port: Max. 30 Watts Power Pin Assignment: (1 / 2) +, (3 / 6)- Output Voltage: 48 V DC |
| Industry Standard | EMI: FCC Part 15, CISPR (EN55022) class A EMS: EN61000-4-2 (ESD) EN61000-4-4 (EFT) EN61000-4-5 (Surge) |
| Working Environment | Working temperature: – 40 °F to 167 °F (- 40 °C to 75 ℃) Storage temperature: – 40 °F to 185 °F (- 40 °C to 85 ℃) Relative Humidity: 5 % to 95 % (no condensation) |
| Weight | N.W: 1.6 lb (730 g) G.W: 1.9 lb (900 g) |
| Dimensions | 6.3 in x 5.4 in x 1.8 in (160 mm x 135 mm x 44 mm) |
