Features
- Support 802.3x full duplex flow control
- Support network storm suppression
- Support IPv6, static routing
- Support DHCP Server, DHCP replay, Qos
- Support Web, SNMP management mode
- Support port mirroring, interface status monitoring, log management
- Support 1588 clock protocol
Technical Specifications
| PoE power | Each port 15 W / 25 W / 30 W |
| Uplink Ports | 2 port SFP slot 1 G |
| Input Voltage | 12 V DC to 57 V DC |
| Device Performance | Surge 6 KV, ESD 15 KV |
| PoE Protocol | IEEE802.3af / IEEE802.3at |
| Throughput | 14.88 Mpps |
| Packet Buffer | 2 M |
| MAC Address | 4K |
| Jumbo Frame | 4096 bytes |
| Fiber Media | Multi-mode: 1.24 ml (2 km)Single mode: 12.43 mi /24.85 mi /37.28 mi / 49.70 mi (20 km / 40 km / 60 km / 80 km) |
| Switching Capacity | 20 Gbps |
| Transfer Mode | Store and forward |
| MTBF | 100,000 hours |
| Protection | Lightening protection, IP40 protection |
| Power Supply | Input Voltage: 12 V DC to 57 V DC / Terminal block |
| Shell | IP40 protect grade, metal shell |
| Installation | DIN-Rail or Wall mounts |
| Network Protocols | IEEE802.3IEEE802.3iIEEE802.3uIEEE802.3abIEEE802.3z |
