Features
- 6 V to 36 V wide voltage DC input
- Support multiple network access methods such as 2G, 3G, 4G and LAN
- Adaptive data transfer rate
- Support 8 channels of concurrent
- Number of accessible nodes is up to 2000
- Supports various operating frequencies
- Effective lightning protection grounding protection
Technical Specification
| Operating frequency | CN 470 MHz, US 915 MHz, EU 868 MHz |
| Transmit power | 23 dBm |
| Receive sensitivity | -142.5 dBm |
| Waterproof rating | IP 67 |
| Voltage | 6 V to 36 V |
| Power consumption | 1 W |
| Access method | LAN, 2G, 3G, 4G |
| Data Protocol | UDP, TCP, MQTT |
| Working temperature | -40 °F to 176 °F (-40 ℃ to 80 ℃) |
| Size | 9.1 in x 8.3 in x 2.2 in (232 mm x 212 mm x 55 mm) |
| Weight | 3.3 lb (1.5 kg) |
