Overview
The Inventory Master lora wan smart agriculture control gateway is a wireless communication router for Internet of things, which provides users with wireless long distance data transmission function by using public wireless network and supports LORA wireless transmission technology for data transmission over short distances. The product adopts the high performance of industrial grade 32 bit communication processor and industrial grade wireless module, supporting platform based on embedded real time operating system software.
Features
- Utilizes Lora private protocol for simplicity, security, and reliability
- Implements time division multiplexing to reduce interference and support
- Offers active report and passive polling with two way transmission
- Supports 2G, 3G, 4G, and Ethernet for versatile data transmission
- Ethernet port operates at 10 mbps to 100 mbps
- Ensures data security and reliability with encryption and verification
- Achieves long distance transmission, up to 2000 meters in an open area
- Built with industrial grade components for harsh industrial environments
Technical Specifications
| Power Supply | 12 V to 24 V DC or AC 220 V |
| Power Consumption | 2 W |
| Working Frequency | 470 MHZ to 510 MHZ |
| Maximum Transmitting Power | 19 DBM ± 1 DBM |
| Communication Rate | 0.2 KBPS to 37.5 KBPS |
| The Antenna | Default omnidirectional FRP antenna 470 MHz to 510 MHz |
| Network Protocol | IP, TCP, UDP, IPV 4 |
| IP Acquisition Mode | Static IP, DHCP |
| User Configuration | Software configuration, AT instruction configuration |
| Standard Spectrum | 850 MHz, 900 MHz, 1800 MHz, 1900 MHz |
| SIM Card | Standard 6 pin SIM card interface, 3 V, 1.8 V SIM card |
| Working Humidity | 0% RH to 95% RH |
| Protection Grade | IP 65 |
| Web Caching | 6 Kbyte to 4 Kbyte |
| Working Temperature | -40 °F to 176 °F (- 40 ℃ to 80 ℃) |
