Features
- Fast read & write, Ulti tags reading, high performance,
- Long read & write distance
- High gain, low VSWR, Good angular orientation
- Superior Waterproof and anti corrosive capability,
- Well adapted to climate
- Waterproof IP67
Technical Specifications
| Frequency Range | 433 MHz ±5 MHz |
| Polarization Type | Horizontal |
| Gain | 6 dBi |
| 3dB Beam Width. H Plan | 80° |
| 3dB Beam Width. E Plan | 75° |
| VSWR | ≤1.5 |
| Front To Back Ratio | ≥12 dB |
| Input Impedance | 50Ω |
| Max Input Power | 50W |
| Lightning Protection | DC Grounded |
| Connector Type | SMA Female |
| Rated Wind Velocity | 60ms |
| Radome Material | PC+ABS |
| Radome Colour | White |
| Operating Temperature Range | -40 ºF to +140 ºF (-40 ºC to +60 ºC) |
| Support Pole Diameter | 1.18 in x 2.36 in (30 mm to 60 mm) |
| Rated Wind Velocity | 60m/s |
| Dimensions | 19.69 in x 6.32 in x 36 in (500 mmx 270 mm x 60 mm) |
