Overview
The Inventory Master PoE load tester is a PoE testing device for POE switch and POE injectors. It’s suitable for testing POE load of multiport switches, it can detect the IEEE802.3 AF or AT standard, voltage and current. It can test the max POE output power by adjusting the current through the ADJ rotary knob. The device suitable for POE equipment manufactures to test the POE parameter of their products. Also, the contractors can use it to test the POE device in normal projects.
Features
- PoE Detection: 802.3 af, 802.3 at
- PoE Input (RJ 45): 42 VDC to 57 VDC
- Compatible Port Speed: 10 M or 100 M or 1000 M
- Adjust current regulation, Test the PoE maximum power
- 4 Ch PoE Load aging test
Technical Specifications
| AT | PoE type IEEE 802.3 at |
| Current | High Current |
| PWR | Machine running |
| A(RJ45) | LED On PoE Pin 12+, 36- |
| B(RJ45) | LED On PoE Pin 45+, 78- |
