Overview
The Inventory Master 4-port fast ethernet PoE switch is a layer two commercial switch that supports MAC auto learning and aging. It has a MAC address capacity of 2 K. The RJ45 ports of this switch support 10 / 100 Mbps self-adaptation. Additionally, it supports IEEE 802.3 af and IEEE 803.3 at power supply standards, allowing for power transmission up to 250 m.
Features
- IP Camera + POE NVR
- IP Camera + POE Switch + NVR
Technical Specifications
| Ethernet Port | 4 x 10 / 100 Mbps PoE ports |
| Power | 48 V DC to 57 V DC power adapter |
| Working Temperature | 14 °F to 131 °F (-10 °C to 55 °C) |
| Application Humidity | 10% to 90% |
| MAC Table Size | 2 K |
| Switching Capacity | 1.8 Gbps |
| Packet Forwarding Rate | 768 Kb |
| Packet Buffer Memory | 890 kpps |
| Flow Control | Enable by default |
| Lightning Protection | Common Mode 2 KV Differential Mode 0.5 KV |
| PoE Protocol | IEEE 802.3 af (PoE), IEEE 802.3 at (PoE+), Hi-PoE |
| PoE Power Consumption | Port 1 ≤60 W, Port 2 to 4 ≤ 30 W, Total ≤60 W |
| Packaging weight | 2.07 lb (940 g) |
| Packaging size | 10.63 in x 9.45 in x 10.83 in (270 mm x 240 mm x 75 mm) |
| Dimension(W×D×H) | 5.12 in x 3.35 in x 1.02 in (130 mm × 85 mm × 26 mm) |
