Overview
The Inventory Master WIFI Protocol UHF Integrated RFID Reader is designed upon fully self-intellectual property. Based on proprietary efficient digital signal processing algorithm, it supports fast tag read/write operation with high identification rate. It can be widely applied in many RFID application systems such as Logistics, Access Control, Anti-counterfeit and Industrial Production Process Control System.
Technical Specifications
| Power Supply | DC 9 V |
| Interface Protocol | EPC global UHF Class 1 Gen 2 / ISO 18000-6C / ISO 18000-6B |
| Spectrum Range | 902 MHz to 928 MHz or 865 MHz to 868MHz or Optional |
| Output Power | 0 dBm to30 dBm |
| Host Communication | RS-232 or TCP/IP |
| Reading Speed | 100 tags per s |
| Antenna Gain | 12 DBI |
| Read Range | 26.2 ft to 49.2 ft (8 m to 15 m) |
| Size | 17.91 in x 17.91 in x 2.17 in (455 mm x 455 mm x 55 mm) |
| Weight | 5.73 lbs (2600 g) |
