Time Domain Reflectometer with User Friendly Interface – The Inventory Master

Name: Time Domain Reflectometer with User Friendly Interface – The Inventory Master - The Inventory Master
SKU: TIMTDRT-143

Discover a reliable time domain reflectometer designed for precise cable fault detection, offering advanced features and ease of use

SKU: TIMTDRT-143 Category: Industrial Ethernet

Features

Measurement Technology	Time Domain Reflectometer (TDR)
Applications	Cable fault detection for power, telecommunications, and coaxial cables
Display	Monochrome backlit graphical display, 128×64 pixels
Power Supply	4 AA alkaline batteries, 1.5 V
Measurement Range	Up to 13,123 ft (4,000 m)
Accuracy	Approximately 1% of the selected range
Resolution	Approximately 1% of the range
Pulse Width	3 ns to 3 µs, auto-adjusted based on range
Output Impedance	Selectable: 25, 50, 75, and 100 Ω
Operating Temperature	14 °F to 122 °F (-10 °C to 50 °C)
Dimensions	6.5 in x 3.5 in x 1.5 in (16.5 cm x 9 cm x 3.7 cm)
Weight	0.88 lbs (0.4 kg)
