Features
- Large touchscreen
- High performance
- Advanced analysis
- Easy to use
Technical Specifications
| Wavelengths | 1310/1550 nm, 1625 nm |
| Display | 9 in touchscreen with high visibility LCD 800×480 |
| Internal Memory | 1 GB |
| Wi-Fi/Bluetooth | Standard IEEE 802.11 b/g and bluetooth class 2 |
| Ethernet | 10/100/1000 MHz |
| USB | 2x USB 2.0 ports |
| Power Meter Power Level | +10 dBm to -60 dBm |
| Power Meter Calibrated Wavelengths | 850, 1310, 1550nm |
| Connector Type (Power Meter) | Universal push/pull (UPP) |
| Visual Fault Locator Wavelength | 635 nm ±15 nm |
| Visual Fault Locator Output Power level | < 1mW |
| Visual Fault Locator Laser Safety | Class 2 laser |
| Talk Set Dynamic Range | 32 dB typical |
| Battery Type | Standard removable liIon |
| AC/DC Adapter | Input 100-250 V, 50-60 Hz; Output 12-15 V DC/3.7A |
| Electrical Safety | EN 60950 compliant |
| Operation Time | Up to 16 hours telcordia GR-196-CORE |
| Dynamic Range | 40/40/38 dB |
| Humidity (Non-Condensing) | 95% |
| Operating Temperature Range (No Option) | -4 °F to 122 °F (-20 °C to 50 °C) |
| Operating Temperature Range (All Options) | 32 °F to 104 °F (0 °C to 40 °C) |
| Storage Temperature Range | -4 °F to 140 °F (-20 °C to 60 °C) |
| Mainframe with Two Modules & Battery | 11.1 in x 6.02 in x 3.8 in (28.2 cm x 15.3 cm x 9.7 cm) |
| Weight | 5.1 lb. with one module and battery (2.3 kg with one module and battery) |
