| Type | Multi-jet Meters, Turbine Meters, Ultrasonic Meters, Prepaid Water Meters |
| Customized Support | OEM |
| Type | Ultrasonic |
| Certificate | CE, ISO4064, ISO9001 |
| Communication Mode | RS485 (Baud Rate is Adjustable), Pulse (Default 2 ml/Pulse), RF, Opt. NB-IoT, GPRS |
| Accuracy | 1.0% |
| Accuracy Class | ISO4064, Accuracy Class 2 |
| Body Material | Stainless Steel 304 (opt. SS316 or SS316L) |
| Battery Life | 15 Years (Consumption ≤0.3 mW) |
| Range Ratio | R500 |
| Max. Working Pressure | 1.6 MPa |
| Pressure Loss | ΔP10,ΔP16(Based on Different Dynamic Flow) |
| Climatic and Mechanical Environment | O Class |
| Electromagnetic Class | E2 |
| Display | 9 Digits LCD Display Volume, Flow Rate, Velocity, Pressure, Error Alarm, Flow Direction, etc. |
| RS485 | Baud Rate 2400 bps, 4800 bps, 9600 bps (Default 9600 bps, Modbus-RTU) |
| Connection | Thread |
| Flow Profile Sensitivity Class | U3/D0 |
| Data Storage | Store the Latest 10 Years’ Data Including Day, Month and Year, The Data Can be Permanently Saved Even Powered off |
| Frequency | 1 times/second or 4 times/second |
| Protection Class | IP68 |
| Temperature Class | T30, T50, T70, T90 (Default T30) |
| Environmental Temperature | -40 °F to 158 °F (-40 °C to 70 °C), ≤100% RH |
| Size | DN32 |
