Technical Specifications
| Grade | Industrial |
| Customized Support | OEM, ODM, software reengineering |
| Range | 0 ft to 26.24 ft (0 m to 8 m) |
| Battery | 3.6 V 17000 mAH |
| Communication | 4G NB-IOT LoRAWAN |
| Measuring Angle | 15° or 20° |
| Accuracy | ±(1 + F.S × 0.3%) cm |
| Production Level | IP66 |
| Lifespan | 5 years (uploading data once an hour) |
| Power Consumption | Standby current ≤80 µA data average sending current ≤150 mA |
| Display | TFT LED display screen |
| Sampling Interval | Per minute |
| Data Transmission Interval | Configuring time 2 min to 1440 min, the less time you configured, the shorter life of the battery |
| Wake-up Mode | Button, timer |
| Configuration Method | USB configuration, sever remote configuration |
| Uploading Information | Level height, distance, battery power, signal, SIM number |
| Measuring Blind Area | 9.84 in (25 cm) |
| Temperature Compensation | Yes |
| Measuring Theory | Ultrasonic |
| Working Time | -22 °F to 158 °F (-30 °C to 70 °C) (no condensing) |
