Features
- Ultrasonic-based non-contact measurement, 16.4 ft measuring range
- Remote monitoring through wireless module
- Threaded mounting or screw mounting
- Inner battery 8500 mAh, low power consumption
- Option for external power supply
- Option for GPS module
- IP67 for outdoor using
- TCP protocol with SDk in Python, Java-script
- Dashboard monitoring or email notification
Technical Specifications
| Use | Level remote monitoring |
| Mounting Type | Threaded mounting or screw mounting |
| Type | Liquid Level Sensor |
| Theory or Principle | Ultrasonic |
| Detection Range | 7.87 in to 196.85 in (20 cm to 500 cm) |
| Blind Area | 0 in to 7.87 in (0 cm to 20 cm) |
| Accuracy | 1.18 in (3 cm) |
| Resolution | 1 mm or 0.1% FS, the bigger one |
| Driving Frequency | 40 kHz |
| Inner Battery | ER26500, 8500 mAh |
| Power | 8500 mAh battery or 3.6 V DC |
| Wireless | NB-IoT, Sigfox, LoRaWAN, 4G, Cat-M |
| Liquid | Diesel, gasoline, water, LPG, Ethanol, and other liquids |
| Protection Level | IP67 |
| Color | Black |
| Operating Temperature | -4 °F to 158 °F (-20 °C to 70 °C) |
| Storage Temperature | -40 °F to 185 °F (-40 °C to 85 °C) |
| Dimension | 4.82 in × 3.74 in × 3.74 in (12.25 cm × 9.5 cm × 9.5 cm) |
