Technical Specifications
| Customized Support | OEM, ODM |
| Output Signal | Support RS485, MODBUS/RTU Protocol |
| Measurement Method | UV 254 dual Wavelength UV Absorption Method |
| COD Range | 0.3 mg/L to 370 mg/L equiv.KHP |
| COD Accuracy | ±5% F.S. equiv.KHP |
| COD Resolution | 0.1 mg/L or 0.01 mb/L equiv.KHP |
| Turbidity Range | 0 NTU to 100 NTU |
| Repeatability | ±1% F.S.equiv.KHP |
| Calibration Method | Two-Point Calibration |
| Response Time | 10sec T90 |
| Power Supply | 12 V or 24 V DC ±10%, 15 mA; 200 mA at brush rotation |
| Protection Class | IP 68, Water Depth 32.8 ft (10 m) |
| Flow Rate | Less Than 3 m/s |
| Service Life | Sensor 3 Years or More, Cleaning Brush System 18 Months or More |
| Cable Length | 16.4 ft (5 m) (default), Customizable |
| Sensor Housing Material | Titanium, 316L, Quartz Glass |
| Maintenance and Calibration Frequency | 3 Months for Sensors, 6 Months for Cleaning Brushes |
| Operating Conditions | 32.18 °F to 122 °F (0.1 °C to 50 °C) |
| Size | Diameter 1.88 in (4.8 cm); Length 7.32 in (18.6 cm); Optional Protective Cover also Available |
