Overview
The Inventory Master’s Wireless LoRaWAN Temperature and Humidity Sensor for Remote Monitoring is a well overcome many shortcomings happened in similar products, with full consideration on tough environment and more. Long range 3.11 mil (5 km), small volume 4.17 in x 2.24 in x 1.30 in (106 mm x 57 mm x 33 mm), long time use features (stand by 3 years with 15 mins interval). Validated by many vital projects with stability and reliance features. LoRa Sensor can collect temp readings with preset interval and send out via LoRa 433 MHz module, then gateway products can translate raw data to temperature and battery voltage information. Widely used in temperature monitoring applications with our gateway product.
Features
- Auto PDF report
- Intuitive LCD indicator
- Built in alarm
- LoRa real time data uploading
Technical Specifications
| Communication | LoRa 433 MHz or 868 MHz |
| Storage Capacity | 50,000 records |
| Transmission Distance | 3.1 mi (5 km) |
| Battery Type | Built-in 3.6 V or 4000 mAh (non rechargable) |
| Alarm Delay | User configurable (0 min to 254 mins) |
| RF Frequency | 433 MHz or 470 MHz or 868 MHz or 915 MHz (optional) |
| Battery Life | Up to 3 years |
| Transmit Interval | 1 min to 1440 min adjustable, default 5 min |
| Waterproof Rating | IP54 |
| Temperature Accuracy | ± 0.54 °F (± 0.3 °C) |
| Humidity Accuracy | ± 3 % RH |
| Temperature Resolution | 32.18 °F (± 0.1 °C) |
| Temperature Range | -22 °F to 140 °F (-30 °C to 60 °C) |
| Humidity Range | 0 % to 90 % RH (Non-condensed) |
| Weight | 5.78 oz (164 g) |
| Dimensions | 4.17 in x 2.24 in x 1.30 in (106 mm x 57 mm x 33 mm) |
