Features
- WiFi Wireless Transmission with Built in Antenna
- Bluetooth Acquisition Device with 12000 mAh, >24 months runtime, and easy clamp install
- Protection class: IP66
- Impact limit: 3.52 o z (100 g)
- Ambient temperature: -40 °F to 185 °F (-40 °C to 85 °C)
Technical Specifications
| Type | Motor vibration sensor | |
| Customized | Yes | |
| Display | Motor status monitor | |
| Rated Voltage | 3.6 V | |
| Working Current | <50 mA | |
| Installation | Clamping or gluing | |
| Functions | Measuring vibration, acceleration, speed, etc. | |
| Features | Mini size, easy to install, wireless communication | |
| Material | ABS + PC | |
| Protection Degree | IP66 | |
| Communication | WIFI MQTT | |
| Vibration Characteristics | Measurement of Vibration Parameters | 3 axes (each axis contains displacement peak value, acceleration peak value, velocity RMS value) |
| Speed Measurement Range | 0.1 cm/s to 20 cm/s (0.01 mm/s to 200 mm/s) | |
| Acceleration Measurement Range | ±0.564 oz (±16 g) | |
| Resolution | 0.032 ft/s2 (0.01 m/s2) | |
| Precision | Acceleration: ±5% @ 80 Hz Speed: ±5% @ 80 Hz Displacement: ±5% @ 80 Hz | |
| Frequency Response Range | 10 Hz to 1600 Hz | |
| Ultrasonic Measurements | Microphone | Range of amplitude: 0.6 mN/m2 to 20 N/m2 |
| Measurement frequency: 100 Hz to 80 kHz | ||
| Power Supply Parameters | Power Supply Method | 3.6 V (Li-ion battery) |
| Battery Capacity | Battery capacity 12000 mAH, 3.6 V | |
| Standby Current | <30 µA | |
| Operating Current | <20 mA during acquisition, <300 mA during data upload | |
| Temperature Characteristics | Resolution | 32.18 °F (0.1 °C) |
| Precision | ±33.8 °F (±1 °C) | |
| Measurement Range | -40 °F to 185 °F (-40 °C to 85 °C) | |
| Working Environment | Hitting the Limits | 3.52 oz (100 g) |
| Ambient Temperature Range | -40 °F to 185 °F (-40 °C to 85 °C) | |
| Housing Parameters | Housing | Stainless steel or reinforced PBT |
| Installation Method | Aluminum clamp, flat bottom mounting (on equipment platform or heat sink bars) | |
| Protection Level | IP66 | |
| Dimension (L×W×H) | 3.38 in × 3.38 in × 1.64 in (8.6 cm × 8.6 cm × 4.19 cm) | |
