Overview
The Inventory Master industrial router is a kind of terminal device developed based on 2G/3G/ 4G, WIFI, and VPN technology. It adopts a high-powered industrial 32-bit CPU and embedded real-time operating system. It supports RS232 (or RS485), Ethernet and WIFI ports that can conveniently and transparently connect one device to a cellular network, allowing it to connect to your existing serial, Ethernet and WIFI devices with only basic configuration.
Technical Specifications
Items | Contents | |
| Hardware System | CPU | Industrial 32 bits CPU |
| FLASH | 16 MB (Extendable to 64 MB) | |
| SDRAM | 128 MB | |
| Interface | WAN | 1 10 or 100 Mbps WAN port(RJ45) |
| LAN | 1 10 or 100 Mbps Ethernet ports(RJ45) | |
| Serial | 1 RS232 or RS485 or RS422 port | |
| Antenna | Cellular: Standard SMA female WIFI: Standard SMA male | |
| Network | Wireless Network | GSM or GPRS or EDGE: 850 or 900 or 1800 or1900MHz WCDMA or HSUPA or HSPA+: 850 or 900 or 1900 MHz or 2100 MHz TDD-LTE: Band 38 or 39 or 40 or 41 & Band 61 or 62 FDD-LTE: Band 1 or 2 or 3 or 4 or 5 or 7 or 8 or 13 or 17 or 20 or 25 or 28 or 66 |
| WIFI | Standard | IEEE802.11b or g or n |
| Bandwidth | IEEE802.11b or g: 54Mbps (max) IEEE802.11n: 150Mbps (max) | |
| Power supply | Standard Power | DC 12 V or 1.5 A |
| Power range | DC 5 V to 35 V | |
| Physical | Dimensions | 5.35 x 3.89 x 1.10in (136x99x28mm) |
| Weight | 0.8 lbs (395 g) | |
| Temperature | Operating Temperature | -35 ℉ to 167 ℉(+75 ºC) (-31 ℉ to +167 ℉) |
