Overview
Our RFID reader boasts versatile features such as adjustable power, multiple working modes, and a waterproof design for outdoor use.
Features
- Protocol support: ISO 18000-6C (EPC C1 Gen2)
- Software with different programming languages allows easy upgrade
- Support RS485, RS232, Wiegand26/34/32/26/66
- The output power is adjustable up to 30dbm
- Supporting various working modes such as timing mode
- Master-slave mode and trigger mode
- Waterproof and sunshine-defending, ideal for outdoor applications
Technical Specifications
| Shell Material | Aluminum alloy |
| RF Interface | SMA outer nut head |
| Antenna Interface | 32 ports |
| Working Frequency | 902 MHz to 928 MHz (US) or 865 MHz to 868 MHz (EU) |
| Reading Distance | 0 to 98.4 ft (0 to 30 m) (Depending on antenna and environment) |
| Communication Port | RS232, RS485, Wiegand (standard), TCP/IP, WIFI, GPRS (selectable) |
| Protocol | (EPC C1 Gen2) ISO 18000-6C |
| Input/Output Port | 2-channel relay output (selectable), 2-channel I/O input |
| Power | 20 dBm to 30 dBm |
| Power Supply | 12 V or 3 A |
| Development Package | Provide DEMO software, SDK & C#, VC, Java development routines |
| Another Configuration | 1M/8M large capacity Flash storage, save when power down, POE power |
| Item Size | 16.1 in x 10.6 in x 4.3 in (410 mm x 270 mm x 110 mm) |
| Net Weight | 4.4 lb (2 kg) |
