Features
- Replaceable battery
- It has different product forms such as key anti-tampering, key anti-tampering + acceleration, etc.
- Reading distance up to 70 meters
- Beacon parameters can be flexibly configured through the mobile APP
- Support BLE4.2 protocol
- Ultra-low power consumption, standby time up to 3 years
- Small and lightweight
- Easy installation
- RoHS Compliant
Technical Specifications
| communication method | BLE 4.2 |
| Operating mode | Broadcasting data |
| Transmit power | -30 db to 4 db |
| Broadcast interval | 100 ms to 10 s |
| Working frequency | 2400 MHz to 2483.5 MHz |
| Transmisson distance | 70 m |
| Current | <=3 uA |
| Peak current | 7 mA |
| RSSI, 1 m | -61 dbm |
| Transmit power | 0 dbm |
| Broadcast interval | 3 s |
| Battery capacity | 225 mAh |
| Working humidity | 10% to 90% |
| Storage humidity | 5% to 90% |
| Working temperature | -4 ºF to 158 ºF (-20 °C to 70 °C) |
| Storage temperature | -4 ºF to 158 ºF (-20 °C to 70 °C) |
