Overview
The Inventory Master Rugged uhf RFID Shelf Tag can be used in tracking management, property management and logistic tracking, specifically designed to perform on metal surfaces. Metal mount RFID tags are typically rugged, difficult to damage, and easy to weld, screw or otherwise attach. RFID Tags are made by ultrasonic packaging, sealing strong. It can be in a humid environment and sandy environment. It can be used in a severe environment for a long time. The RFID transponders are available for mounting on metal, plastic or wood using standard M5 screws, industrial adhesives or welding. Rugged RFID hard tags are also good for item identification, process control, factory automation, access control and security. What’s more, inventory control, supply chain management and large rental equipment are also workable. It’s also a nice choice for RFID pallet tracking system. This tag can be mounted directly on the metal surface, using an anti-metal layer to make it work.
Features
- Capable for reading on, off and near metal surfaces
- Rugged design for long-term outdoor
- Wide read range
- Provides glue, screw, rivet
- Support silk-print
- Programming and encoding
Technical Specifications
| Communication Interface | RFID, NFC |
| Special Features | MINI TAG |
| Frequency | 860 MHz to 960 MHz |
| Protocol | EPC Global UHF Class 1 Gen 2 (ISO 18000-6C) |
| Chip | MF S50 or S70 or Ultralight or I CODE or F08 or Ntag213 or Various Chips available |
| Material | ABS |
| Special Features | Aluminum Antenna, Coated Paper |
| Craft | Laser Code or UV Ink or Serial Number or Embossing or Thermal Printing |
| Memory | EPC 96 bit to 480-bit, User 512 bit, TID 32 bit |
| Max Read Distance | 393.7 in (10000 mm) |
| Antenna Material | Aluminum |
| Tag Materials | Polyurethane |
| Craft | Logo, Serial Number or Code |
| Application | Logistics, Asset Management, Stock Control, Warehouse Management, Item Tracking |
| Operating Temperature | -31 °F to 149 °F (-35 ºC to +65°C) |
| Storage Temperature | -58 °F to 167 °F (-50 °C to+75 °C) |
| Inlay Size | 2.8 in X 0.9 in (73 mm X 23 mm) |
| Antenna Size | 2.7 in X 0.6 in (70 mm X 17 mm) |
