Technical Specifications
| CPU | Allwinner T507 Quad core main frequency 1.5GHz |
| Memory | LPDDR4 2GB |
| Storage | 8G eMMC |
| USB host | 2 channel high speed USB HOST |
| Ethernet | 1 channel WAN port, 4 channel LAN port （10 or 100 or 1000Mbps self-adaptive） |
| WIFI | IEEE 802.11b or g or n |
| 4G | LTE Cat1 |
| CAN bus | 1 channel |
| HDMI | 1 channel HDMI output support 4K 60fps output |
| Power supply | DC 10.5 V to 28V |
| Power protection | Reverse protection, wrong wire protection |
| Power consumption | ＜5W |
| Withstand voltage | 500VAC （1 min） |
| Insulation resistance | over 500Ω （500VDC） |
| Anti-vibration | -10 to 25Hz（X, Y, Z direction 2G or 30 min) |
| Working temperature | 14 ℉ to 122 ℉ (-10 to 50 ℃) |
| storage environment | -4 ℉ to 140 ℉ (-20 to +60℃) |
| Environment humidity | 10 to 90%RH (no condensing) |
| Cold method | Natural wind cold |
| Body shell material | Aluminum alloy |
| Dimension | 5.5 in x 4.33 in x 1.97 in (140 mm x 110 mm x 50mm) |
| Installation method | GB C45 din rail |
| Protection level | IP20 |
| Weight | 17.64 oz (500g) |
