Technical Specifications
| CPU | 6th Gen Celeron Skylake SOC Processor Default 3855U Dual Core Processor, 1.6 GHz, 2M Cache |
| CPU TDP | 15W |
| Memory (RAM) | 1 x DDR4 SO-DIMM Socket (4 GB or 8 GB or 16 GB or 32 GB, 2133 MHz or 2400 MHz) |
| Chipset | By CPU |
| Graphics | HD Graphics 510 |
| Graphics Card Chipset | Integrated Card |
| LAN Chipset | 2 x Realtek Gigabit LAN |
| Audio | Realtek HD Audio |
| Watch Dog | Yes |
| WIFI | Optional |
| OS Support | Windows 10, Linux Windows 7 (Only for 6th Gen Skylake) |
| Front I or O Power Button | 1 |
| Front I or O LED | 1 x Power LED 1 x HDD LED |
| Front I or O Serial Port | 1 x RS-232 |
| Front I or O USB | 4 x USB 2.0 2 x USB 3.0 |
| Rear I or O Power | 1 x DC Jack |
| Rear I or O Video Output | 2 x HD Video 1 x VGA |
| Rear I or O LAN | 2 x Realtek Gigabit LAN |
| Rear I or O USB | 2 x USB 3.0 |
| Rear I or O Audio | 1 (Line-out, Mic-in) |
| Rear I or O Serial Port | 0 |
| Storage Type | 1 x (6.35 cm) 2.5-inch HDD or SSD 1 x M key M.2 for SSD (Type: 88.97 in (2260 mm), 89.76 in (2280 mm)) |
| Expansion Mini PCIe | 1 x Mini PCIe Full-length for 4G, Half-length for Wi-Fi |
| Expansion M.2 | 1 x M.2 for SSD (M key, 89.76 in (2280 mm)) 1 x M.2 for Wi-Fi (E key, 87.79 in (2230 mm)) |
| Expansion GPIO | 1, 2 x 5Pin, Pitch 0.07 in (2.0 mm) |
| Expansion SIM Card Slot | 1 |
| Expansion RS-485 | 0 |
| Expansion Serial Port | 0 |
| Expansion CMOS Clear Jumper | Yes, 1 x 3Pin, Pitch 0.07 in (2.0 mm) |
| Expansion Automatically Boot Jumper | Yes, 1 x 3Pin, Pitch 0.1 in (2.54 mm) |
| Power Adapter | 12V5A |
| DC Jack | 0.21 in (5.5 mm), 0.09 in (2.5 mm) |
| Material | Aluminum Alloy |
| Mounting | VESA Mounting Bracket |
| Kensington Lock | No |
| Cooling Mode | Fanless Design |
| Humidity | 10%RH to 90%RH |
| Operating temperature | 32°F to 122°F (0°C to 50°C) |
| Non-operating temperature | -4°F to 176°F (-20°C to 80°C) |
| Dimension | 7.71 in x 4.80 in x 1.85 in (196 mm x 122 mm x 47mm) |
| Weight | 2.75 lbs (1.25 kg) |
