Technical Specifications
| Output | 0 k ohm to 5 k ohm |
| Measuring range | 10 mm (0.39 in), 25 mm (0.98 in), 50 mm (1.97 in), 75 mm (2.95 in), 100 mm (3.94 in), 125 mm (4.92 in), 150 mm (5.91 in) |
| Linearity | 0.1 % FS |
| Mounting type | Linear potentiometer |
| Housing material | Polycarbonate |
| Response time | 25 µs, 50 µs, 100 µs, 300 µs |
| Shock proof | 500 m/s² (50G) 3 times each for X, Y, Z direction |
| Connection | 6.56 ft PVC cable (2 m) |
| Ambient temperature | 14 °F to 131 °F (-10 °C to 55 °C) (no icing) |
| Weight | 3.17 oz (90 g) |
