Technical Specifications
| RAM | DDR2:128MB |
| FLASH | Default 16MB |
| Ethernet Port | 2 x 10 or 100Mbps Fast Ethernet Port, WAN or LAN |
| Industrial Serial Interface | RS485 x 1 Industrial terminal RS485 Signal:A,B,G ESD Protection 8KV |
| Reset button | Pinhole type reset button |
| SIM card holder | Drawer type card holder |
| Wi-Fi | 802.11b or g or n 300Mbps |
| Grounding terminal | Support |
| Transmitting Power | 802.11b 16dBm ± 2dBm (11Mbps) 802.11g 15dBm ± 2dBm (54Mbps) 802.11n 2.4GHz 13dBm ± 2dBm (HT20 MCS7) |
| Max. Power: < 8W | < 8W |
| Working Power | 150mA 24V (HSAP+network) |
| Power Interface: | 4 PIN Vehicle mounted locking terminals |
| Standby Power: | 100mA 24V (HSPA+network) |
| Peak power | 180mA 24V (HSPA+network) |
| Network Typ | Support LTE, WCDMA(HSPA+) EDGE GPRS |
| LAN protocol | Support ARP, Ethernet |
| IP routing | Static routing |
| Firewall: | Stateful Packet Inspection (SPI), DoS attack defense, Multicast filter or Ping probe packet, Access Control List (ACL), NAT, PAT, DMZ, port mapping, and virtual server |
| Embedded watchdog | Device runs self-detection, auto recovers from malfunctions |
| Link Detection Embedded | Sends heartbeat packets to detect, auto redials when disconnected |
| Mounting method: | Din-Rail mounted, Wall-mounted |
| Shell | Metal Structure |
| Protection class | IP30 |
| Packing Size | 7.08 in x 5.70 in x 2.16 in (180 mm X 145 mm X 55 mm) |
| Dimensions
| 2.75 in x 3.14 in x 1.181 in (70 mm x 80 mm x 30 mm)
|
| Operating temperature | -40 °F to 167 °F (-40 °C to 75 °C) |
| Storage temperature | -40 °F to 212 °F (-40 °C to 100 °C) |
| Ambient Humidity | 10% to 90% RH non-condensing |
| Storage Humidity | 5% to 90% RH non-condensing |
