Technical Specifications
| 4G-CAT.1 Frequency band | LTE-FDD: B1 or B3 or B5 or B8 LTE-TDD: B34 or B38 or B39 or B40 or B41 |
| 4G-CAT.4 Frequency band | LTE-FDD: B1 or B2 or B3 or B4 or B5 or B7 or B8 or B12 or B13 or B18 or B19 or B20 or B25 or B26 or B28 LTE-TDD: B38 or B39 or B40 or B41 WCDMA: B1 or B2 or B4 or B5 or B6 or B8 or B19 GSM or EDGE: 850 or 900 or 1800 or 1900 |
| 5G frequency band | 5G NR NSA: n41 or n78 or n79 5G NR SA: n1 or n28 or n41 or n77 or n78 or n79 |
| WIFI Standard | 802.11 b or g or n 2.412 GHz to 2.484 GHz |
| 2G Frequency band | GSM: 900 MHz or 1800 MHz |
| Client Configuration | Serial port configuration, network port configuration, remote configuration |
| Source | DC 24 V, working range (DC 9 V to28 V), anti surge, overcurrent, and reverse connection protection |
| Average Power | ≤5 W |
| Networking Methods | 2G or 4G (CAT.1) or Network cable |
| Communication Port | 1 X WAN or 1 X LAN 1 X 485 or 1 X 232 |
| Collection Interval | ≥ 500 ms |
| Number of device drivers | 50 |
| Number of variables | 500 |
| Variable Expansion | Supported (up to 10000), please consult customer service for details |
| Number of system variables | 200 |
| Number of reported topics | 50 |
| Write variable themes | 10 |
| Reading Variables themes | 10 |
| Scripting Language | Javascript |
| Number of scripts | 10 |
| PLC Remote download | All serial or network devices (PLC, touch screen, others) |
| South bound agreement | Modbus, Siemens, Mitsubishi, Omron, Delta, Xinjie, AB, Keinz, Huichuan, Yaskawa, Panasonic, Megumit, Hollyssey, Beifu, DLT645, BACnet and other protocols (most serial or network PLC) |
| Northbound Agreement | Support mainstream or private MQTT platforms (generally compatible with all MQTT platforms) Supports HTTP, UDP, and TCP protocols |
| Reporting Method | Periodic timing change |
| Breakpoint continuation | Have |
| Gateway debugging | Have |
| Template import | Have |
| Remote configuration platform | Have |
| Time server | Have |
| Intermediate variable | support |
| Cooling Method | Natural air cooling |
| SM card holder | 1.8 V or 3 V, drawer type card holder |
| Reset | Pin hole reset button |
| Data interface | RS232: 1200 bps to 115200 bps RS485: 1200 bps to 115200 bps
LAN port: 10 or 100M adaptive Ethernet port meeting IEEE802.3 to 2005 standard WAN port: 10 or 100M adaptive Ethernet port meeting IEEE802.3 to 2005 standard |
| Antenna Interface | SMA Female Interface |
| Mobile APP Add or configure devices | Have |
| Work Environment | -31 °F to 167 °F (-35 ℃ to 75 ℃) 10 % RH to 90 % RH |
| Size | 4.4 in X 3.3 in X 1.3 in (114 mm × 85 mm × 35 mm) |
