Technical Specifications
| Chip | Impinj R2000 |
| Spectrum Range | 860 MHz to 960 MHz (customized optional) |
| Protocol | EPC global Class1 Gen2, ISO 18000-6C |
| Transmission Mode | FHSS or fixed frequency, Support RSSI |
| RF Output Power | 33 dBm |
| Operating Modes | Passive mode, real-time inspection mode |
| Anti-Collision Modes | Supports EPC, TID, USER, EPC+TID |
| Peak Inventory Speed | >700 tags per s |
| Tag Buffer Size | 1000 tags at 96 bits EPC |
| Data Operations | Supports EPC and TID area data read/write |
| Power Supply | Single +12V power supply, optional POE |
| Communication Interfaces | RS232, USB, RJ45 (TCP/IP), WIFI (optional), 4G (optional), POE (optional) and others |
| I/O Control | 2 channels of input control (5V signal), 2 channels of output control (5 V signal), 2 channels of relay control |
| Software Support | Free Windows, Linux & Android DEMO software and SDK for testing and development |
| SDK | Supports X86 & X64, C++, C#, VB, Delphi, Linux, ARM, Python, NodeJS, QT, JAVA, Android |
| Temperature Sensor Support | Supports temperature sensor RFID tag and the normal RFID tag |
