Features
- 16 Channels
- Multi-Backhaul
- GPS Support
- DC/Solar Power
- Internal Antennas
- External LoRa Antenna
- Dying-Gasp Option
Technical Specifications
| Enclosure | IP67/NEMA-6 industrial-grade with cable glands |
| Power Supply | PoE (802.3af) with Surge Protection |
| LoRa Concentrators | Dual concentrators for up to 16 channels |
| Backhaul | Wi-Fi, LTE, and Ethernet |
| GPS | Supported |
| Power Options | DC 12V or Solar power supply with electricity monitoring (Solar Kit optional) |
| Antennas | Internal antennas for Wi-Fi, GPS, and LTE; External antenna for LoRa |
| Dying-Gasp | Optional |
| Chipset | mt7628 |
| Applications | LoRaWAN solutions, Water Meter AMR system |
| Network Server | Built-in Network Server |
| VPN Support | OpenVPN |
| Software/UI | Built on OpenWRT |
| LoRaWAN Version | LoRaWAN 1.0.3 |
| LoRa Frame Filtering | Node whitelisting |
| MQTT | MQTT v3.1 bridging with TLS encryption |
| Packet Buffering | Buffering of LoRa frames in Packet Forwarder mode during NS outages (no data loss) |
| Duplex Mode | Full duplex (optional) |
| Listen Before Talk | Optional |
| Fine Timestamping | Optional |
