Technical Specifications
| Frequency | 865 MHz to 868 MHz, 902 MHz to 928 MHz or 920 MHz to 925MHz |
| Protocol | EPC C1 GEN2 or ISO18000-6C |
| Communication Interface | USB 2.0 Type-C, OTG |
| Display | 5.2 in (13.2 cm) IPS FHD |
| R Or W Range | > 22.9 ft (7 m) (Linear Polarization, Outdoors); 68.8 ft (21 m) (Linear Polarization, Indoors) >32.8 ft (10 m) (Circular Polarization, Outdoors); > 82.0 ft (25 m) (Circular Polarization, Indoors) |
| Reading Rates (Circular Polarization) | > 200 Tags Per s (Circular Polarization) |
| Antenna | Linear Polarization (1.8 dBi) or Circular Polarization (4 dBi) |
| Operating System | Android 6.0 (Quad-core) or Android 8.1 (Octa-core) |
| Language | Java |
| Tool | Eclipse or Android Studio |
| Camera | 13 MP Autofocus with flash |
| CPU | Cortex-A53 Quad-core 1.45 GHz or Cortex-A53 Octa-core 2.5 GHz |
| RAM + ROM | 2 GB + 16 GB(Quad-core) or 3 GB+32 GB (Octa-core) |
| Expansion | Supports up to 128 GB Micro SD card |
| Bluetooth | Bluetooth 4.0, BLE |
| Touch Panel | Corning Gorilla Glass, multi-touch panel, gloves and wet hands supported |
| Power | Main battery: Li-ion, rechargeable, 8000 mAh Standby: over 500 hrs Continuous use: over 12 hrs Charging time: 3 to 4 hrs |
| Expansion Slot | 1 slot for SIM card, 1 slot for SIM or TF card |
| Interfaces | USB 2.0 Type-C, OTG, Octa-core version supports Type C headphones |
| Audio | Speaker, 2 microphones |
| Keypad | 4 front keys, 1 power key, 2 scan keys, 1 multifunctional key |
| Sensors | Gravity sensor, light sensor, proximity sensor |
| Humidity | 5 % RH to 95 % RH noncondensing |
| Drop Specification | Multiple (1.5 m) 4.9 ft drops to the concrete across the operating temperature range |
| Tumble Specification | 1000 x (0.5 m) 1.64 ft falls at room temperature |
| ESD | ±15 KV air discharge, ±6 KV conductive discharge |
| 1D Linear Scanner (Quad-Core) | Zebra SE965 / Honeywell N4313 |
| 1D Symbologies | UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc. |
| 2D Imager Scanner (Quad-Core) | Zebra: SE4710 / SE4750 / SE4750MR; Honeywell: N6603 |
| 2D Imager Scanner (Octa-Core) | Zebra: SE4750/ SE4750MR |
| 2D Symbologies | PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal (KIX), etc. |
| NFC Frequency | 13.56 MHz |
| Operating Temperature | – 4 °F to 122 °F (-20 ℃ to 50 ℃) |
| Storage Temperature | – 40 °F to 158 °F (-40 ℃ to 70 ℃) |
| Size | 6.4 in X 3.1 in X 0.9 in (164.2 mm X 80 mm X 24.3 mm) |
| Weight | 23.0 oz (654 g) |
